EL-DC4P DC STRÖMBRYTARE 4Р/32А, 1000V 32А

EL-DC4P DC STRÖMBRYTARE 4Р/32А, 1000V 32А

98SOL4P/DC
  1. Varumärke ELMARK
  2. Jämföra Skriv ut
  • Pris:
    649 . 55 kr Inklusive moms
  • Kvantitet (pcs) :

I lager

I lager
KÖP KLAR ATT SKICKA

Tekniska data

  • Volt 1000V
  • Märkström 32 A
  • Antal poler 4
  • IP-kod IP66
  • Garanti
  • DC switches shall be installed between the solar arrays and solar inverter for isolation the PV array during system installation or any maintenane.


    TECHNICAL DATA:


    • Rated insulation voltage (Ui): 1200V

    • Rated heating current (Ith): 32A

    • Poles: 4P

    • Mechanical life: 10 000 cycles

    • Operating temperature: -25 to +70°C

    • Storage temperature: -40 to +70°C

    • IP code: IP66

    • Handle colour: Black


    FEATURES:


    • Vertical and horizontal installation

    • UV resistance

    • Flame retardant material

    • Breatle valve

    • Lockable at off position
